Hi Link HLK-10M03 10W 3.3V AC DC Power Supply Module

Description:

The Hi Link HLK-10M03 is a compact and efficient 10W AC/DC power supply module designed for various electronic applications. It provides a stable and reliable 3.3V output voltage with high efficiency and low ripple.

Key Features:

• High efficiency and low power consumption
• Compact size and lightweight
• Wide input voltage range
• Short circuit and overload protection
• High reliability and long lifespan
• Cost-effective solution

Specification:

• Input Voltage: 85-264VAC
• Output Voltage: 3.3V
• Output Power: 10W
• Output Current: 3A (Max)
• Efficiency: >85%
• Ripple and Noise: <100mVp-p
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +105°C

DATA SHEET AND USECASE

Key Features:

• Wide Input Voltage Range: Operates with input voltages from 85 to 264VAC or 70 to 350VDC, making it suitable for global applications.

• High Efficiency: Designed for high efficiency and low power consumption, with no-load power consumption ≤0.1W.

• Safety and Protection: Features input-output isolation voltage of 3000VAC, and includes protections against short circuits and over-current conditions with self-recovery capabilities.

• Compact Design: Its ultra-thin and small form factor (46.9mm x 27.8mm x 21.8mm) allows for integration into space-constrained applications.
