18650 Battery Shield For Arduino ESP8266 Raspberry Pi Generic

Power Up Your Raspberry Pi with the Pi18650 Dual Battery HAT

Elevate your Raspberry Pi projects with the Pi18650 Dual Battery HAT. This versatile module provides a reliable and efficient power solution, ideal for both home and professional applications.

Key Features:

• Dual Battery Capacity: Power your Raspberry Pi with two 18650 lithium-ion batteries for extended runtime.
• Intelligent Charging: Built-in charging circuits allow you to conveniently charge the batteries via the USB Micro connector.
• Precise Battery Monitoring: Monitor battery status in real-time using the included I2C-based Python script.
• Flexible Power Options: Utilize a DC power supply, adapter, or even a solar panel to charge the batteries.
• Customizable Control: The jumper enables you to isolate the battery circuit, start the Pi, or integrate with external systems.
• Versatile Applications: Power robots, motors, and other devices with the additional Micro USB connector and screw terminal.

Specifications:

• Maximum Charge Current: 1A per battery
• Maximum Output Current: 6A for Raspberry Pi
• Input Voltage: Up to 18V DC
• Battery Type: 18650 lithium-ion
• Connector: 26/40 pin for Raspberry Pi
• Charging Connector: USB Micro
• Voltage Regulation: 5.1V

Additional Features:

• LED Indicators: Monitor charging status with visual cues.
• Reverse Battery Protection: Safeguard your device from accidental misconnections.
• Standoffs for Support: Ensure secure mounting and stability.
• Wifi Header: Connect to an ESP8266 or custom board for wireless connectivity.

Benefits:

• Extended Battery Life: Power your Raspberry Pi for longer durations without frequent recharging.
• Reliable Power Supply: Ensure consistent and stable power for your projects.
• Customizable Control: Integrate with your system for automated power management.
• Versatile Applications: Power a wide range of devices and projects.

DATA SHEET AND USECASE

Key Features:

• Power Outputs:

  • Provides both 5V and 3V outputs.
  • 5V output can supply up to 2.2A, with some models supporting up to 3A.
  • 3V output typically supplies up to 1A.

• Charging and Protection:

  • Equipped with a Micro USB port for charging the 18650 batteries.
  • Features overcharge, over-discharge, and short-circuit protection to ensure battery longevity and device safety.

• Indicators and Controls:

  • LED indicators: Red signifies charging, while green indicates a full charge.
  • Includes a switch to control the USB output, allowing for manual power management.
