Description:
The Meco MC 27T-Auto Temp Digital Clampmeter is a versatile and reliable tool designed for various electrical measurements and temperature readings. It offers a wide range of features, including auto-ranging for AC current and voltage, making it suitable for professionals and DIY enthusiasts alike.
Key Features:
- Auto-Ranging: Automatically selects the appropriate measurement range for AC current and voltage, ensuring accurate readings.
- Temperature Measurement: Equipped with a K-type thermocouple for precise temperature readings.
- Large LCD Display: Provides clear and easy-to-read measurements.
- Audible Continuity Test: Emits a beep to indicate continuity, simplifying troubleshooting.
- Diode Test: Enables quick and efficient testing of diodes.
- Data Hold Function: Freezes the current reading on the display for convenient analysis.
- Low Battery Indication: Warns the user when the battery is low, preventing unexpected shutdowns.
- Auto Power Off: Conserves battery life by automatically turning off the meter after a period of inactivity.
Applications:
- Electrical Troubleshooting: Diagnosing electrical faults in household appliances, industrial equipment, and automotive systems.
- HVAC Maintenance: Measuring temperature in heating and cooling systems.
- Automotive Diagnostics: Checking battery voltage, alternator output, and other electrical components.
- General Electrical Work: Performing various electrical measurements, such as voltage, current, and resistance.
DATA SHEET AND USECASE
Key Features:
- Display: 3½-digit LCD with 2000 counts.
- AC Current Measurement: Auto-ranging across 2A, 20A, 200A, and 600A ranges.
- Voltage Measurement:
- AC Voltage: Auto-ranging across 2V, 20V, 200V, and 600V ranges.
- DC Voltage: Auto-ranging across 200mV, 2V, 20V, 200V, and 600V ranges.
- Resistance Measurement: Auto-ranging up to 20MΩ.
- Temperature Measurement: Ranges from -20°C to 750°C (-4°F to 1400°F) using a K-type thermocouple.
- Additional Features: Data hold, audible continuity, diode test, auto power off (APO), backlight display, torchlight for clamp, non-contact voltage detection (NCV) with LED and buzzer indicators, and low battery indication.
- Jaw Opening: Accommodates cables up to 25mm in diameter.
- Power Supply: Two 1.5V 'AAA' batteries, providing approximately 200 hours of operation.
- Dimensions and Weight: Approximately 185 x 65 x 28 mm and 170 grams (including batteries).
