Metal Gear Side Shaft Motor 100 RPM

Metal Gear Side Shaft Motors with a 100 RPM rating are versatile components commonly used in various applications, particularly in robotics and automation. They offer a balance of speed and torque, making them suitable for a wide range of tasks.

Key Features:

• 100 RPM Speed: Provides a controlled and moderate rotational speed.
• Metal Gearbox: Ensures durability and efficient power transmission.
• Side Shaft Design: Offers flexibility in mounting and orientation.
• Compact Size: Suitable for space-constrained projects.
• Low Noise Operation: Ideal for quiet applications.

Applications:

• Robotics: Used in robot arms, grippers, and locomotion systems.
• Automation: Employed in conveyor systems, assembly lines, and other automated processes.
• Model Making: Powering various mechanisms in model vehicles, boats, and aircraft.
• DIY Projects: Used in custom-built devices and gadgets.

DATA SHEET AND USECASE

Typical Specifications:

• Rated Voltage: 12V DC
• No-Load Speed: 100 RPM
• No-Load Current: Approximately 0.17 A
• Rated Torque: Ranges from 7 kg.cm to 42 kg.cm, depending on the specific model
• Stall Torque: Up to 42 kg.cm
• Shaft Diameter: Typically 6 mm
• Shaft Length: Varies by model, commonly around 15 mm to 30 mm
• Gearbox Diameter: Approximately 37 mm
• Motor Diameter: Around 28.5 mm
• Weight: Approximately 300 grams
