TIP122 NPN Power Darlington Transistor 100V 5A TO-220 Pack 8

The TIP122 is a high-power NPN Darlington transistor designed for demanding applications that require high current and voltage ratings. It's a versatile component suitable for a wide range of electronic circuits, from power amplifiers to motor control.

Key Features:

• Wide Operating Temperature: Can operate from -55°C to 150°C.
• NPN Transistor: Offers both amplification and switching capabilities.
• TO-220 Package: A popular package for power transistors, providing good heat dissipation.
• High Power Rating: Handles up to 5A of continuous collector current and 100V between collector and emitter.
• Darlington Configuration: Provides higher current gain and lower input impedance compared to a single transistor.

Applications:

• Motor Control
• Power Supplies
• Power Amplifiers
• Switching Circuits
• Industrial Automation

DATA SHEET AND USECASE

Key Features:

• Package Type: TO-220
• Collector Current (I_C): 5A​
• Power Dissipation (P_D): 65W​
• at I_C = 3A, V_CE = 3V​
• Collector-Emitter Voltage (V_CEO): 100V​
• DC Current Gain (h_FE): Minimum of 1000
