2.54mm Female Berg strip 40x2 Pin Straight header 4 pcs

2x40 Pin Female Breakaway Header: Versatile and Reliable

Upgrade your electronics projects with this essential 2x40 pin female breakaway header. Designed for easy integration into PCBs, it offers a reliable and efficient connection for various applications.

Key Features:

• 2x40 Pins: Provides ample connections for your projects.
• 2.54mm Pitch: Compatible with standard pin headers and PCBs.
• Breakaway Design: Allows for easy customization and individual pin removal.
• Through-Hole Mounting: Securely integrates into your PCB.
• Versatile Applications: Suitable for a wide range of electronic projects.

Applications:

• Microcontroller and IC Pin Extensions: Increase connectivity options.
• Electronic Prototyping: Experiment with different circuit configurations.
• Industrial Automation: Connect components in industrial systems.
• Laboratory Equipment: Use in research and development settings.
• Hobby Projects: Power and control various electronic devices.

Specifications:

• Connector Type: Pin Header
• Gender: Female
• Number of Pins: 40 (2 rows)
• Pin Spacing: 2.54mm
• Mounting Type: Through-Hole
• Configuration: Straight

Choose the 2x40 pin female breakaway header for a reliable and versatile solution in your electronics projects.

DATA SHEET AND USECASE

Key Specifications:

• Pin Configuration: 2 rows of 40 pins each, totaling 80 pins.
• Pin Pitch: 2.54mm (0.1 inches).
• Mounting Type: Through-hole.
• Contact Material: Typically brass or phosphor bronze.
• Insulation Material: Commonly PBT (Polybutylene Terephthalate) UL 94V-0 rated.
• Contact Resistance: Approximately 20mΩ.
• Insulation Resistance: Around 1000MΩ.
• Dimensions:
  • Length: Approximately 102mm.
  • Width: Around 4mm.
  • Height: Approximately 8mm.
