DESCRIPTION:
The 3 Pin JST XH connector is a popular type of electrical connector used in a variety of applications. It features a compact design and a pitch of 2.54mm, making it ideal for connecting small-gauge wires. The connector typically includes a male and female part, each with three pins.
APPLICATION:
The 3 Pin JST XH connector is commonly used in the following applications:
- Robotics: For connecting sensors, actuators, and other components
- Electronics: For prototyping, circuit boards, and other electronic devices
- LED Lighting: For connecting LED strips and other lighting components
- Model Trains: For connecting tracks, lights, and other accessories
- RC Vehicles: For connecting batteries, motors, and other components
KEY FEATURES:
- Compact design
- Pitch of 2.54mm
- Three pins
- Male and female parts
- Easy to assemble and disassemble
- Reliable and durable
DATA SHEET AND USECASE
Key Specifications:
- Current Rating: Up to 3 A AC/DC (using AWG #22 wire)
- Voltage Rating: 250 V AC/DC
- Applicable Wire Range: AWG #30 to #22
- Operating Temperature Range: -25 °C to +85 °C (including temperature rise when applying electrical current)
