CK06KK-X7R-9BB106 (10uf / 50V) Pack 30

Description:

Enhance your electronic circuits with our high-quality 1.5nF X7R MLCC capacitor. This versatile component offers precise capacitance and reliable performance for a wide range of applications.

Key Features:

• Compact Design: 1206 package for efficient space utilization on PCBs.
• Reliable Performance: Adheres to industry standards for quality and reliability.
• Accurate Capacitance: 1.5nF capacitance for precise energy storage in your circuits.
• Temperature Stability: Operates reliably from -55°C to +125°C for demanding environments.
• Versatile Applications: Ideal for various electronic circuits, including power supplies, filters, and coupling circuits.

Technical Specifications:

• Dielectric: X7R
• Tolerance: 10%
• Capacitance: 1.5 nF
• Voltage Rating: 50V
• Case/Package: 1206
• Mount: Surface Mount
• Composition: Ceramic
• Minimum Operating Temperature: -55°C
• Maximum Operating Temperature: 125°C

DATA SHEET AND USECASE

Key Specifications:​

• Capacitance: 10 µF​
• Quantity: Pack of 30
• Voltage Rating: 50 V​
• Dielectric Material: X7R​
• Passive Component: +9
• Package: CK06 (a specific case size)​

Applications:

X7R dielectric capacitors are classified as temperature-stable ceramics and are widely used in various applications due to their reliable performance over a broad temperature range. Common uses include:​

• Coupling Capacitors: Used to transmit AC signals between different stages of amplifiers while blocking DC components.​
• Timing Circuits: In RC (resistor-capacitor) timing circuits, X7R capacitors can be used where moderate accuracy is acceptable.​
• Decoupling and Bypass Capacitors: They help filter out unwanted noise in electronic circuits by providing a low-impedance path to ground for high-frequency signals.​
• Filtering Applications: Suitable for use in both low-pass and high-pass filter designs, especially where stability over temperature is required.
