PulsEvo Power 18650 Li-Ion 6600mAh 12v 3S3P Protected Battery Pack

Description :

The PulsEvo Power 18650 Li-Ion 6600mAh 12v 3S3P Protected Battery Pack is a high-capacity rechargeable battery designed for various applications requiring reliable and consistent power. Here's a breakdown of its key features:

Specifications:

• Capacity: 6600mAh
• Voltage: 12V
• Cell configuration: 3S3P (3 cells in series, 3 cells in parallel)
• Chemistry: Lithium-ion (Li-ion)
• Protection: Built-in protection circuit for overcharge, over-discharge, short circuit, and overcurrent protection
• Dimensions: 72 x 65 x 54 mm
• Weight: 570g

Features:

• High capacity: Provides long-lasting power for various devices and applications.
• 12V output: Suitable for devices that require a 12V power supply.
• 3S3P configuration: Offers a balance between capacity and voltage.
• Built-in protection: Ensures safe and reliable operation.
• Compact size: Lightweight and portable for easy carrying and installation.
• Long life: Can withstand up to 1000 charge cycles.

Applications:

• Power tools: Drills, saws, grinders, etc.
• Electronic devices: Cameras, video recorders, portable speakers, etc.
• Medical equipment: Portable devices for monitoring and diagnostics.
• Hobby and DIY projects: RC cars, drones, robots, etc.
• Emergency lighting: Backup power for LED lights and flashlights.

Charging:

• Recommended charger: 15V 1A/2A SMPS with DC jack.
• Charging time: Approximately 4-5 hours.

Important Safety Notes:

• Always use a compatible charger.
• Do not charge in extreme temperatures.
• Avoid overcharging and over-discharging.
• Store in a cool, dry place.
• Handle with care to avoid damage.

Additional Information:

• Model: 18650 Li-Ion 6600mAh 12v 3S3P Protected Battery Pack
• Availability: Available online and in select electronics stores.

DATA SHEET AND USECASE

Key Specifications:

• Nominal Voltage: 11.1V
• Capacity: 6600mAh
• Configuration: 3S3P (3 series, 3 parallel)
• Cell Type: 18650 lithium-ion cells
• Built-in Protection: Incorporates a protection circuit module (PCM) to safeguard against overcharge, over-discharge, overcurrent, and short circuits.
