Water Flowing Light LED Module NE555+CD4017 DIY Kit Generic

The Water Flowing Light LED Module NE555+CD4017 DIY Kit Generic is a versatile electronic project that creates a visually appealing water flow effect using LEDs and a combination of the NE555 timer and CD4017 decade counter integrated circuits.

Key Features:

• NE555 Timer: Generates the timing signals that control the LED sequence.
• CD4017 Decade Counter: Sequences through the LEDs, creating the illusion of flowing water.
• LED Array: Consists of multiple LEDs arranged in a linear or circular pattern to simulate the flowing water effect.
• DIY Kit: Comes as a kit with all the necessary components for easy assembly.
• Customizable: Can be customized with different LED colors, patterns, and timing sequences to create unique effects.

Applications:

• Decorative Lighting: Used to create visually appealing lighting effects for homes, offices, or events.
• Educational Projects: Can be used to teach electronics, programming, and circuit design.
• DIY Projects: Popular for DIY enthusiasts to create custom lighting effects and electronic projects.

DATA SHEET AND USECASE

Technical Specifications:

• Operating Voltage: 5V – 12V DC

• ICs Used: NE555 Timer, CD4017 Decade Counter

• Number of LEDs: 10

• Adjustable Speed: Via potentiometer or by changing resistor/capacitor values

• Power Consumption: Low

• PCB Size: Compact design, typically around 54mm x 21mm
