4 Pin Slide Type 2 Row DIP Switch Pack 2

4-Position DIP Slide Switch

Versatile Configuration Control

This 4-position DIP switch offers a convenient and flexible way to configure and control various electronic circuits. Its compact design and easy-to-use slide mechanism make it ideal for a wide range of applications.

Key Features:

• 4 Individual Positions: Fine-tune your settings with precision
• 2.54mm Pin Spacing: Compatible with breadboards and PCBs
• Slide Switch Mechanism: Simple and reliable operation
• Through-Hole Mounting: Easy integration into your circuits
• Pre-Tinned Leads: Facilitates soldering and connections

Applications:

• Electronics: CPU modulation, wireless communication, broadcast, TV
• Automation: Control systems, machinery settings, and more

DATA SHEET AND USECASE

Specifications:

• Contact Rating: Typically 25 mA at 24 VDC.

• Contact Resistance: Generally ≤ 50 mΩ.

• Insulation Resistance: Usually ≥ 100 MΩ at 500 VDC.

• Dielectric Strength: Commonly around 500 VAC for 1 minute.

• Operating Temperature Range: Typically -20°C to +70°C.
