74HC595 8-bit Serial to Parallel Shift Register IC Pack 5

74HC595N: A Versatile 8-Bit Shift Register

The 74HC595N is a powerful shift register IC designed to expand the input/output capabilities of your microcontroller. It efficiently converts between serial and parallel data formats, allowing you to control multiple peripherals using fewer microcontroller pins.

Key Features:

• 8-Bit Serial-In, Parallel-Out: Accepts serial data and outputs it in parallel format, simplifying microcontroller-to-peripheral communication.
• Low Power Consumption: Consumes minimal power, making it suitable for battery-powered or energy-efficient systems.
• Wide Operating Voltage Range: Operates from 2V to 6V, accommodating various power supply options.
• High-Speed Performance: Offers a typical shift out frequency of 100 MHz, ensuring fast data transfer.
• Versatile Applications: Ideal for expanding microcontroller I/O, controlling LEDs, driving motors, and other applications.

Applications:

• Peripheral Expansion: Increases the number of controllable peripherals for your microcontroller.
• LED Control: Drives multiple LEDs with precise control over brightness and patterns.
• Motor Control: Used in motor control applications for driving stepper motors or other motors.
• Data Processing: Employed in data processing applications for serial-to-parallel data conversion.

Specifications:

• Supply Voltage: 5V
• Supply Current: 70mA
• Total Power Dissipation: 500mW
• Input: 8-bit serial input
• Output: 8-bit serial or parallel output
• Shift Out Frequency: 100 MHz (typical)
• Package: DIP-16
