IRF 9540 MOSFET IC DIP-3 Package by IRR

The IRF9540 MOSFET IC is a high-performance power semiconductor device designed for a variety of electronic applications. It's particularly well-suited for high-voltage, high-current switching applications, such as those found in power supplies, motor drives, and inverters.

Key Features:

• High Voltage Rating: Can handle voltages up to 600V, making it suitable for high-power applications.
• Fast Switching Speed: Offers a high switching frequency, enabling efficient power conversion.
• High Current Capability: Can handle large currents, making it suitable for demanding applications.
• Low On-Resistance: Provides minimal power dissipation when conducting, leading to higher efficiency.
• DIP-3 Package: A popular package format for discrete semiconductors, providing easy integration into circuit boards.

Specifications:

• Package: DIP-3
• Input Capacitance : 3000p
• Gate Charge : 120nC (typical)
• On-Resistance : 0.045Ω (typical)
• Drain-Source Breakdown Voltage: 600V

Applications:

• Inverters
• Motor drives
• Power supplies
• Switching regulators
• Industrial control systems

DATA SHEET AND USECASE

Key Specifications:

• Total Gate Charge: 61nC​
• Power Dissipation: 150W​
• Pulsed Drain Current: Up to -76A​
• On-Resistance (R_DS(on)): 200 mΩ​
• Gate-Source Voltage (V_GS): ±20V​
• Drain-Source Voltage (V_DS): -100V​
• Continuous Drain Current (I_D): -19A​
• Operating Junction Temperature Range: -55°C to 175°C
