Slide Switch DPDT 6 Pin Pack 5

SPDT Slide Switch

Compact and Versatile

This SPDT (Single Pole, Double Throw) slide switch is a reliable and easy-to-use component for your electronic projects. It's ideal for controlling circuits and connecting different components.

Key Features:

• SPDT Configuration: Offers two stable positions for controlling circuits
• Compact Design: Small size for space-constrained applications
• Durable Construction: Built to withstand long-term use
• Easy Installation: Mounting holes at both ends for convenient placement

Specifications:

• Contact Type: SPDT
• Terminal Pins: 3
• Contact Resistance: 20MΩ
• Voltage Max: 50V
• Current Max: 0.5A
• Material: Plastic and Metal

Applications:

• Small Power Electronics: Control circuits, power supplies, and other devices
• DIY Projects: Create custom electronic gadgets and prototypes
• General-Purpose Switching: Connect and disconnect components in various circuits

DATA SHEET AND USECASE

Technical Specifications:

1. C&K JS Series Sub-Miniature Slide Switches (DPDT):

   • Datasheet:

   • Features:
     • Positive detent
     • Low profile
     • IR reflow to 260º solder profile
     • Available in SPDT, DPDT, and DP3T models
     • RoHS compliant
   • Applications: Telecommunication products, computer peripherals, thermostat select switches, instrumentation, medical devices.

2. CW Industries GF-126-0305 DPDT Slide Switch:

   • Datasheet:

   • Features:
     • On-On switch function
     • Current rating: 3A (AC), 500mA (DC)
     • Voltage rating: 125 V (AC and DC)
     • Through-hole mounting with PC pin termination
     • Operating temperature range: -10°C to 104°C
   • Applications: Suitable for applications requiring a compact switch with reliable performance.
