SMD to DIP DIP8 DIP16 SOIC8 SOIC16 Adapter SOP8 SOP16 IC

Description:

SMD to DIP adapters are small, specialized circuit boards that allow you to use Surface Mount Devices (SMD) in through-hole applications. These adapters convert the small, surface-mounted components into a format that can be easily inserted into breadboards, proto boards, or sockets with through-hole pins.

Key Features:

• Compatibility: Available for various SMD packages, including DIP8, DIP16, SOIC8, SOIC16, SOP8, and SOP16.
• Versatility: Enable the use of modern SMD components in older or more accessible prototyping environments.
• Convenience: Simplify the process of working with SMD components, especially for beginners or those without specialized equipment.
• Reusability: Can be used repeatedly with different SMD components.

Specifications:

• Package Types: DIP8, DIP16, SOIC8, SOIC16, SOP8, SOP16 (and others)
• Pin Count: Varies depending on the package type
• Material: Typically made of FR4 (fiberglass reinforced epoxy) or other suitable PCB materials
• Dimensions: Compact size for easy handling and integration

DATA SHEET AND USECASE

Product Specifications:

1. SOIC-16 / SOP-16 SMD to DIP Adapter by SchmalzTech:

   • Description: Converts SOIC-16 / SOP-16 SMD parts to a DIP form factor, facilitating easy prototyping with surface-mount parts.
   • Specifications:
     • DIP Pitch: 0.1"
     • SMD Package: SOIC-16/SOP-16
     • Surface Finish: LF HASL
     • Temperature Rating: -30°C to +100°C

2. Ximimark SOIC8 SOP8 to DIP8 IC Programmer Socket Converter:

   • Description: Adapter module designed for converting SOIC8/SOP8 to DIP8, suitable for 25xx EEPROM Flash programming.
   • Features:
     • Compatible with various programming devices
     • Supports both 150mil and 200mil IC body widths

3. SOP16 TO DIP16 Programmer Adapter by Waveshare:

   • Description: Enplas IC programmer adapter compatible with SOP8-SOP16, SO8-SO16, SOIC8-SOIC16 packages.
   • Features:
     • High-quality and durable construction
     • Tested before shipping
     • Easy to use

4. SOP8 to DIP Program Adapter - Type A by Micro Robotics:

   • Description: Adapter compatible with SMD 8-pin chips (SO-8 150mil), featuring high-quality slim-type gold pins suitable for most ZIF and DIL/DIP sockets.
   • Applications:
     • Supports chips like 24CXX, 93CXX
     • Compatible with various programmer series
