Hi Link HLK 20M24 24V/20W Switch Power Supply Module

Description:

The Hi-Link HLK-20M24 is a compact and efficient switch-mode power supply module designed for various electronic applications. It converts 100-240V AC input to a stable 24V DC output, making it suitable for powering a wide range of devices.

Key Features:

• Compact Size: Its small footprint allows for easy integration into space-constrained designs.
• High Efficiency: Minimizes energy loss, resulting in lower operating costs and reduced heat generation.
• Universal Input Voltage: Operates reliably across different AC voltages worldwide.
• Stable Output: Provides consistent 24V DC power, ensuring reliable operation of connected devices.
• Low Ripple and Noise: Minimizes interference with sensitive electronic components.
• Multiple Protections: Built-in safeguards against short circuits, overcurrent, and overload conditions.

Specifications:

• Input Voltage: 100-240V AC
• Output Voltage: 24V DC
• Output Power: 20W
• Efficiency: Up to 93%
• Ripple and Noise: <100mVp-p
• Operating Temperature: -25°C to 60°C
• Storage Temperature: -40°C to 80°C
• Dimensions: 56x32x22.5mm

DATA SHEET AND USECASE

Key Features:

• Wide Input Voltage Range: Supports universal AC input from 100V to 240V, accommodating global voltage standards.

• High Efficiency: Designed for high efficiency and power density, ensuring minimal energy loss during operation.

• Low Power Consumption: Features low no-load power consumption, making it environmentally friendly.

• Protection Mechanisms: Equipped with output short circuit and over-current protection with self-recovery capabilities.

• Isolation Voltage: Provides input and output isolation with a withstand voltage of 3000VAC, enhancing safety.
