HLK-PM12 from Hi-Link is a isolated power supply module with input range of 100 volt to 240 volt AC and output of DC 12 volt and power rating of 3 watt. Its ultra-compact size makes it perfect to use in places where size is a constraint. It is a compact PCB mountable plastic enclosed power supply module. HLK-PM12 Power Supply Module replaces lots of parts from the traditional power supply like diodes, voltage regulator and transformer.
There are many advantage of these modules, such as ：Global input voltage range, low temperature rise, low power, high efficiency, High reliability, high security isolation, etc.
It has been widely used in smart home, automation and control, communications equipment, instrumentation and other industries, when applied to electromagnetic compatibility relatively harsh environment, reference should be circuit.
Product features:
1. Meet UL, CE requirements
2. Ultra-thin, ultra-small
2. All voltage input (AC: 90 ~ 264V)
3. Low ripple and low noise
4. Output overload and short circuit protection
5. High efficiency, high power density
6. The product is designed to meet the requirements of EMC and Safety Test
7. Low power consumption, environmental protection, no-load loss <0.1W
8.100% load aging and testing
9.1 year warranty period
Environment Condition
Store Temperature: -40 - +80 ℃
Relative humidity: 5 - 95 %
Cooling way: Cooling by radiation
Atmospheric pressure: 80 - 106 KPa
Sea level elevation: Less than 2000 m
Vibration: Vibration coefficient, 10~500Hz, 2G10min./1cycle, 60min.each along X,Y,Z axis
Electrical Characteristic
