Hi Link HLK-10M09 9V 10W Power Supply Module

Description:

The Hi Link HLK-10M09 is a compact and efficient AC-DC power supply module designed to convert standard AC voltage (90-240V) into a stable 9V DC output. It is ideal for powering various electronic devices and projects that require a reliable and regulated 9V power source.

Key Features:

• Compact Size: Its small footprint makes it suitable for space-constrained applications.
• High Efficiency: It delivers a high level of power conversion efficiency, minimizing energy loss and heat generation.
• Global Compatibility: It can operate on a wide range of AC input voltages, making it suitable for use worldwide.
• Overload Protection: It incorporates built-in protection mechanisms to safeguard against overloads and short circuits.
• Low Ripple and Noise: It provides a clean and stable DC output with minimal ripple and noise, ensuring optimal performance for sensitive electronic devices.

Specifications:

• Input Voltage: 90-240V AC
• Output Voltage: 9V DC
• Output Current: 1.1A
• Output Power: 10W
• Dimensions: 46.9 x 27.8 x 21.8mm
• Weight: 45g

DATA SHEET AND USECASE

Key Features:

• Input Voltage Range: 85-264V AC / 70-350V DC
• Output Voltage: 9V DC
• Output Current: 1.1A
• Output Power: 10W
• Isolation Voltage: 3000V AC between input and output
• No-load Power Consumption: ≤0.1W
• Operating Temperature Range: -25°C to +60°C
• Protections: Overload and short circuit protection with self-recovery
• Certifications: Designed to meet UL/CE standards
