Hi Link HLK-30M12 12V 30W Switch Power Supply Module

Description:

The Hi-Link HLK-30M12 12V 30W Switch Power Supply Module is a compact and efficient AC-to-DC power supply designed for various electronic applications. It converts standard AC input voltage (90V-265V) into a stable 12V DC output, providing reliable power for your devices.

Key Features:

• High Efficiency: Delivers up to 90% efficiency, minimizing energy loss and reducing heat generation.
• Compact Size: Its small footprint saves space in your projects or installations.
• Wide Input Voltage Range: Operates seamlessly with both 110V and 220V AC inputs.
• Overload and Short Circuit Protection: Built-in safety mechanisms safeguard your devices from damage.
• Low Ripple and Noise: Ensures clean and stable DC output for sensitive electronics.

Specifications:

• Input Voltage: 90V-265V AC
• Output Voltage: 12V DC
• Output Current: 2.5A
• Output Power: 30W
• Efficiency: Up to 90%
• Ripple and Noise: ≤70mVp-p
• Dimensions: 57.5 x 33.6 x 22.5mm
• Weight: 81g

DATA SHEET AND USECASE

Key Features:

• Wide Input Voltage Range: Supports 85–264V AC, accommodating global voltage standards.
• High Efficiency: Achieves up to 90% efficiency, reducing energy loss.

• Low No-Load Power Consumption: Consumes less than 0.1W when idle, promoting energy efficiency.
• Compact Design: Measures approximately 56mm x 32mm x 22.5mm, facilitating integration into space-constrained projects.

• Protection Features: Includes output short circuit and over-current protection with self-recovery capabilities.
