Hi Link HLK-40M09 9V 40W Switch Power Supply Module

Description:

The Hi-Link HLK-40M09 is a compact and efficient switch-mode power supply module designed to provide a stable and reliable 9V DC output at a maximum power of 40W. It is ideal for a wide range of applications where a regulated DC power source is required, such as industrial control systems, telecommunications equipment, and consumer electronics.

Key Features:

• High Efficiency: Converts AC input to DC output with minimal power loss, resulting in energy savings and reduced heat generation.
• Wide Input Voltage Range: Accommodates various global AC mains voltages, making it suitable for worldwide use.
• Compact Size: Small footprint for easy integration into space-constrained designs.
• Overload and Short-Circuit Protection: Built-in safety mechanisms to protect the module and connected devices from damage.
• Isolated Output: Provides electrical isolation between the input and output, enhancing safety and reducing noise.
• Low Ripple and Noise: Ensures clean and stable DC output for sensitive electronic components.

Specifications:

• Input Voltage: 85-264VAC
• Output Voltage: 9VDC
• Output Current: 4.4A (maximum)
• Output Power: 40W (maximum)
• Efficiency: Typically >85%
• Ripple and Noise: <70mVp-p (typical)
• Overload Protection: Yes
• Short-Circuit Protection: Yes
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Dimensions: 57 x 33 x 22.5mm
• Weight: 81g
