Description Reviews

Description:

HLK-5M09 Hi-Link 9V 5W AC to DC Power Supply Module is a plastic enclosed PCB mounted isolated switching step-down power supply module. It can supply 9V DC from 100V AC 240V AC and has a power rating of 5Watt. This makes it perfect for small projects that need a 9 volt supply from mains. This power supply module replaces lots of parts from the traditional power supply like diodes, voltage regulators, and transformers.

Features:

All voltage input (AC): 90 ~ 264V
Technical indicators: Single bit
Working temperature: 20-60 +degree
Storage temperature: -40-+80 Degree Celsius
Relative humidity: 5-95%
The cooling way: Natural cooling
The atmospheric pressure: 80-106Kpa
The altitude: 2000M or less.

Package Includes:

1 x HLK-5M09 Hi-Link 9V 5W AC to DC Power Supply Module

DATA SHEET AND USECASE

Key Features:

Wide Input Voltage Range: Supports 100V to 240V AC, making it suitable for global use.
Stable Output: Provides a consistent 9V DC output at up to 555mA, ensuring reliable performance for connected devices.
Isolation: Features input and output isolation voltage of 3000VAC, enhancing safety and protecting connected devices.
Compact Design: Its small form factor allows for easy integration into various electronic projects, especially where space is limited.
