Hi Link HLK-PM09 Power Supply 220V to 9V 3W AC-DC Circuit Converter Module

Sold By

DSMElectro Solutions Private Limited

(1249 customer reviews)

Top Selling Products

Resistor SMD 1206 10K Pack 10

74% OFF

~~₹39~~ ₹11
Digital LED Temperature Controller XH-W3001 12V 120W

41% OFF

~~₹399~~ ₹236
LCD 16x2 Blue Display

40% OFF

~~₹199~~ ₹120
IR tracker sensor

54% OFF

~~₹99~~ ₹46
LiPo Rechargeable Battery High-Quality 3.7V 500mAh

57% OFF

~~₹599~~ ₹258
Relay Module 12V Single Channel

64% OFF

~~₹99~~ ₹37
NEMA17 Planetary Geared Hybrid Stepper Motor 25KGCM Reduction Ratio 1:5

25% OFF

~~₹4,999~~ ₹3,775
LiPo Rechargeable Battery High-Quality 3.7V 380 mAh

25% OFF

~~₹399~~ ₹300

Description Reviews

Description:

HLK-5M09 Hi-Link 9V 5W AC to DC Power Supply Module is a plastic enclosed PCB mounted isolated switching step-down power supply module. It can supply 9V DC from 100V AC 240V AC and has a power rating of 5Watt. This makes it perfect for small projects that need a 9 volt supply from mains. This power supply module replaces lots of parts from the traditional power supply like diodes, voltage regulators, and transformers. Therefore there are many advantages for these modules, such as low-temperature rise, low power, high efficiency, high reliability, high-security isolation, etc.

Features:

All voltage input (AC): 90 ~ 264V
Technical indicators: Single bit
Working temperature: 20-60 +degree
Storage temperature: -40-+80 Degree Celsius
Relative humidity: 5-95%
The cooling way: Natural cooling
The atmospheric pressure: 80-106Kpa
The altitude: 2000M or less.

Package Includes:

1 x HLK-5M09 Hi-Link 9V 5W AC to DC Power Supply Module

DATA SHEET AND USECASE

Key Features:

Wide Input Voltage Range: Supports 85-264VAC, making it suitable for global use.
High Efficiency: Offers up to 73% conversion efficiency.
Isolation: Provides 3000VAC isolation between input and output, enhancing safety.
Compact Design: Measures approximately 34mm x 20mm x 15mm, ideal for space-constrained applications.
Protections: Includes over-current and short-circuit protection with self-recovery capabilities.
Compliance: Meets UL and CE standards, ensuring quality and safety.
