FEATURES:
High efficiency, long life, and high reliability
Low dc ripple, high efficiency
low operation temperature & long performance life
Excellent insulation property, high dielectric strength
100% full-load burning test
Dimension: 200*95*45
Input -
Specification:
AC input voltage range(V):AC 110V/220V±15% (switch replacement)
Input current(A):6.5A /115V,4A /230V
Frequency (Hz):50/60Hz
Efficiency:87% Typ(230VAC Full Load)
Inrush current(A):25A/115V 50A/230V cold start
Leakage current(mA):<3.5mA/240VAC
Output - Specification:
Output Voltage(V):+12VDC
Output Current(A):10A
Current Range (A):0-10A
Rated Power(W) :120W
Start time, hold-up time(ms):Ton≤200ms,Td≥30ms @230Vac Full Load
Rise time(ms):Typ:100ms @230Vac Full Load
Ripple/Noise(mVp-p):150mVp-p
Protection:
Over voltage Protection: >115%-135% Rated output voltage
Over load Protection: >105%-150% Auto recovery
Short circuit Protection: Latched
